RockSchmidt Rock Testing

Name: Rockschmidt Type L
Brand: Gardco
SKU: 15027
Price: 3298 USD
Availability: InStock

Art. No.: 15027

Rockschmidt Type L

Select your Model

Hardness Testers

$3,298.00

QTY

Enter a value between 1 and 100000000 in increments of 1.

excl. taxes & shipping cost

Rock testing using rebound hammer technology
Impact angle independent
Displays the impacts on-screen as you work
Select standard on instrument
Work with hammer independently and upload later if desired to connected app
Connect to iOS, android and portable printer
Swiss made hammers specifically designed for rock testing with multiple applications – UCS, E-modulus, weathering grade
Best in class correlations to unconfined compressive strength (UCS)
Instant data back-up and collaboration features
Unique optical measurement system ensures low dispersion and maximum accuracy in comparison with classical hammers ·
Work with the hammer alone, or using the mobile app for fast documentation of your measurements and secure sharing via Screening Eagle Workspace
Rock Schmidt App allows you to:
- Correlate directly to USC or e-modules
- Take advantage of existing correlations
- Apply polynomial or exponential correlations
- Set units and limits for correlation
- Build your own database for different rock types
- Visual report generation using lists, bar charts and statistics
- Single and multiple series export in PDF or CSV export
- Works with rock testing standards ASTM D5873, and rebound value and weather determination ISRM guidelines

Technical Data Chart

Data

Measurement:	Automatic calculation of rebound value according to international standards
Technology:	Optical rebound velocity quotient
Impact Energy:	N 2.207 Nm / L 0.735 Nm
Display:	Analog & backlit digital (100 x 100 pixels, graphic)
Connectivity:	Bluetooth® LE, USB for charging and updates
Weight:	0.84 kg / 1.85 lbs
Battery:	Standard AAA rechargeable
Battery Lifetime:	>20,000 impacts between charges
Operating Temperature:	0 to 50°C / 32 to 122°F
Storage Temperature:	-10 to 70°C / 14 to 158°F
Operating Humidity:	<95% RH, non-condensing
Languages:	English, German, Japanese, Chinese, Korean, Spanish, Portuguese, Italian, French, Russian
