Portable Analog Shore Durometers
Art. No.: 11730
Portable Shore D scale, Analog Durometer
- Shore Analog Durometer
- D Scale
Select your Model
Enter a value between 1 and 100000000 in increments of 1.
excl. taxes & shipping cost
- The Economy Portable Analog Shore Durometer conforms to Shore A and Shore D style hardness scales.
- Accurate and easy-to-read hardness scale
- Manufactured in accordance with DIN, ASTM, ISO & JIS specifications
- Perfect for testing the hardness of flexible materials such as rubber & plastics
- Test pieces should have a thickness of at least .20”/5mm to provide accurate readings that conform to Shore A hardness scales and at least .12”/3mm for Shore D hardness scales
- Penetrator: Blunt taper 35°
- Graduation: 1 Shore
- Manufactured in accordance with DIN, ASTM, ISO & JIS specifications
- The test piece side should be smooth and have sufficient area to support the base of the hardness tester
- Applications - 35° blunt taper Durometers are suitable for testing soft and natural rubber products, neoprene, polyesters, soft P.V.C., leather, thiokol, nitril rubbers, wax, felt and more
Portable Shore D scale, Analog Durometer
- Reference test block
- Operating instructions
- Fitted case
- Manufacturer test certificate
Portable Shore A scale, Analog Durometer
Article No: 11729
