SMP Series Melting Point Apparatus

Article No. 13296

SMP20 Digital Melt Point Apparatus, 120V

  • SMP20 Melting Point Apparatus
  • Temperature to 0.1 degree resolution
  • Variable ramp rate and hold key so that the exact melt temperature can be recorded
  • 240V

Select your model

$1,967.00 excl. taxes & shipping cost


  • The SMP10 and SMP20 have been designed with safety and ease of operation in mind making it ideal for use in education.
  • The temperature is selected, measured and displayed digitally making it accurate and negating the need for a thermometer.
  • Clear observation and use - Two samples can be tested simultaneously. They are viewed via a magnifying lens with clear observation aided by built in illumination.
  • Extendible back feet allow the unit to be operated at the optimum viewing angle.
  • Full access to the block aids cleaning.
  • The simple to follow instructions are printed directly on the instrument in most European languages for ease of use.

Technical Attributes

  • Data
    Part No.:1510513296
    No. of Samples:2
    Temperature Range:Ambient to 300°C
    Temperature Resolution:±1.0°C at 20°C, ±2.5°C at 300°C
    Display:3 Digit LED4 digit LED
    Display Resolution:1°C0.1°C
    Display Hold Facility:NoYes
    Ramp Rates:20°C per min plateau, 2°C per min to melt20°C per minute plateau variable between 1-10°C
    per minute to melt
    Language Variants:English, German, French, Italian, Spanish
    Dimension HxDxW (mm):160 x 220 x 170mm
    Net Weight (lbs):4 lbs/1.8 kg


To operate simply select a plateau temperature via the digital display and press “start”. The unit quickly heats up and remains at the selected plateau temperature until the user is ready to start the test. Insert the sample tubes and press “start”.

The unit then heats at a fixed rate of 2°C per minute for the SMP10 and at a user selected rate of between 1 and 10°C per minute for the SMP20. When the sample is seen to melt, note the temperature on the display. Press “stop” to end heating and cool the block.
