Immersion Circulators

Article No. 13286

Immersion Circulator TE-10D, 240V

Immersion Circulators Thermoregulators are "clip-on" style and designed to be used with the Techne® unheated water baths or any suitable laboratory vessels. They heat, circulate and safely control the temperature of liquid in the bath within precise limits. They convert your existing liquid bath, or unheated bath or container, into a precision temperature controlled bath with an exceptional thermal performance.

Select your model

$2,399.00 excl. taxes & shipping cost


  • Specifications to DIN 58966
  • Temperature range of -40°C to 120°C
  • Excellent temperature stability: ±0.01°C at 40°C
  • 4 digit setting with a bright LED digital temperature display
  • Suitable for most routine laboratory applications
  • User adjustable over-temperature cut-out
  • Low liquid level cut-out as standard
  • Full range of options such as external circulation or digital set/ readout, high pump output and RS232 interface available

Technical Attributes

  • Data
    Temperature Range °C:*-40 to +120
    Temperature Selection:Digital
    Temperature Stability Using Water @ 40°C:±0.01
    Method of Control:PID
    Temperature Sensor:PRT
    Adjustable Over Temp Cut-Out:Yes
    Low Liquid Level Cut-Out:Yes
    Pump Capacity liters/minute:10
    Pump Capacity (mbar):145
    Nominal Heater Power@120V:50/60 Hz / 1000 Watts
    @ 240V:50/60 Hz / 1000 Watts
    Dimensions (mm) Extensions Below Base:145
    Overall size (LxWxH) (mm):237 x 124 x 260
    Shipping Weight:3.9 (kg)
    * Refrigeration or cooling coil required for below ambient cooling.
