BMW Single Impact Tester

Article No. 5200

esp-10
BMW Single Impact Tester

  • Portable design to run tests outside the laboratory
  • Can be used in a cooling chamber with temperatures = - 10°C
  • Impact tool with wedge-shaped blade
  • Compressed air of 3 bars accelerates the ball
$9,890.00 excl. taxes & shipping cost

Features

Measures chip resistance of multi-coat automotive finishes

  • Instrument in accordance with BMW standard
  • Ideal to assess formulation changes or application process

Technical Attributes

    Technical Specifications

  • Connection for Compressed Air
    R 1/8"
  • Compressed Air Supply
    5 bar
  • Operational Life of Impact Tool
    approx.1000 impacts
  • Working Pressure
    3 bar
  • Additional Weight
    1.75 kg (3.9 lbs)
  • General

  • Weight
    8.6 kg
  • Weight
    19 lb
  • Dimensions: L x W x H
    23 x 32 x 35 cm
  • Dimensions: L x W x H
    9.1 x 12.6 x 13.8 in

Standards

DIN EN ISO

20567-2

Delivery Content

Single Impact Tester esp-10
Weight
Connection hose
Manual
