Vortex Mixer HS-8 Open

Vortex Paint Mixer

Art. No.: 15408

Vortex Mixer, 1 Gal, HS-8

The HS-8 Vortex Mixer is the perfect solution for fast and homogenous mixing of paint and viscous materials in both round and squared 1-gallon cans.

Select your Model

$1,740.00

Enter a value between 1 and 100000000 in increments of 1.

excl. taxes & shipping cost

  • Operator's safety is granted by the strictest design and material specifications
  • Quart adapter is included
  • Stable running low noise, mix quickly thoroughly
  • Convenient to install and load can
  • Adjustable mixing time from 0 to 15 minutes
  • Revolution speed 265 RPM
  • Rotation speed 410 RPM
  • Easy to operate and maintain
  • Safety switch on the access door
  • Wood crate standard packaging

Technical Data Chart
Data
Power Settings:Single Phase 110 V 60 Hz ± 10%
Max Load:11 lb. (5 kg)
Max Can Height:200 mm
Min. Can Width/Depth:170 mm
Max. Base Can Dims:169 mm
Max Power Consumptions:180 W
Working Temperature:10˚ - 40˚
Relative Humidity:5% - 85% (not condensing)
Size (HxWxD):680 x 420 x 580 mm
Weight:214 lb. (97 kg)
Shipping Size (HxWxD):800 x 510 x 690 mm
Shipping Weight:258 lb (117 kg)
