Pencil Durometers

Article No. 11623

Type D Pencil Durometer

The 202 ASTM Type D Pencil Durometer measures hard rubber, plastics, epoxies and similar materials. The instrument uses a dial gauge with a full 360° scale and bold easy to read numbers. The dial scale can easily be read to 1/2 point readings.

    $950.00 excl. taxes & shipping cost


    • 1/2" diameter base allows access to confined, hard to reach areas.
    • Accuracy of ±1 point
    • Max reading pointer standard and max-hold hand remains at the peak reading until reset.
    • Meet or exceed all aspects of ASTM D2240 specifications
    • Certification traceable to NIST is available for nominal cost
    • New barrel design has a textured surface for a more secure grip while making hand held measurements.

    Technical Attributes

    • Data
      Accuracy:±1 point
      Height:5-5/16 in. (13.5 cm)
      Width:2-1/4 in. (5.7 cm)
      Depth (Indicator):1-1/2 in. (3.8 cm)
      Weight:6.5 oz. (184 g)
      Shipping Weight:3 lb. (1.4 kg)


    Meets or Exceeds Current ASTM D2240 Specifications

    Delivery Content

    Durometer comes complete with a precision aluminum test block and carrying case
